Technical Specifications
| Size | 268/240 x 181 x 28 mm | FM Mode | Wide spectrum FM (FHSS) or fixed frequency, software programmable |
| RF Output | 30 dBm adjustable; 50 ohm load | Frequency Range | American Standard 902-928MHz or European Standard 865-868MHz |
| Indication Mode | LED indicator | Mounting Method | Screw fixing |
| Protection Class | IEC IP65 | Reading Distance | 9dbi antenna configuration, 6-10 m |
| Power Consumption | Average power consumption <10W | Communication Rate | Serial port rate 9600～115200bps, RJ45 10Mbps |
| Interface Protocol | EPCglobal UHF ISO-18000-6C (EPC G2), ISO-18000-6B | Software Interface | DLL & Demo Source Code Provided |
| Communication Interface | RS232, USB (Slave), RJ45 (TCP/IP), optional WiFi, etc. |
